Main features:
- The tubes are sealed with a pressure cap and then released onto a bucket conveyor at the machine's exit, with the cap facing the operator.
- The machine boasts a highly compact design for feeding tubes.
- Tubes are transported using bushes that move with synchronized dynamic actions.
- Tablets are inserted using a pick-and-place system that ensures positive placement.
- The machine is built in strict accordance with GMP standards.
- Features a cantilever or "balcony" design.
- Designed to distinctly separate the operational area from the sections containing mechanical and electrical components.
- Constructed from steel and aluminum, with panels made of AISI304 stainless steel. All parts that come into direct contact with the product are made of appropriate materials.
PRODUCT RANGE | |
Tubes Diameter | From 16 to 40 mm |
Tubes Length | From 60 to 160 mm |
Tablets Diameter | 14 to 35 mm |
Tablets Thickness | From 3 to 8 mm |
Cap Diameter | From 18 to 44 mm |
Cap Collar height | From 1 to 10 mm |
tablets/min | Up to 1.000 |
